35KW Sponge Mattress Foam Production Line High Speed 220L / Mould

Brand Name : D&T

Model Number : DTPUF-75

Place of Origin : China

MOQ : 1set

Price : USD35000~56000 / Set

Payment Terms : T/T, L/C, Paypal

Supply Ability : 10 sets per month

Delivery Time : 45days

Packaging Details : packed with pvc film into 1*40HQ

Item : Batch Box Foaming Machine

Product Size : 3000*2000mm

Product Height : below 1100mm

Chemical : PPG, TDI, MC, Silicone+H2O, T9, A33, etc.

Density : 10Kg/m³~60Kg/m³

Maximum capacity : 220L/mould

Production capacity : 230kg/h

Total Power : 35KW

Foaming model : Semi-automatic

application area : sponge, polyurethane foam, mattress, furniture

Contact Now

35KW Sponge Mattress Foam Production Line High Speed 220L / Mould

Product Description

2). Main Technology Data:

Max.Product Size: 2400mm×2000mm (L×W)

Max. Product Height: 1200mm

Quantity of component of foaming material: 7 (PPG, TDI, MC, Water, Silicone oil, T9,A33)

Density: 10Kg/m³~60Kg/m³

Maximum capacity: 150L/mould, discontinual Foaming(two moulds), 6~10 blocks per hour

Touch scream and semi-automatic control system with 100 foaming formula

Power of Mixing Head: 7.5kw(Brake motor)

Total Power: 30KW

3). Configuration

3.1 Components (total 7 components)

No.	Component	Material Tank	Out-feed Pump	specification
1	PPG	3 Ton,A3 Steel	CB-7	Feeding Pump, Mixing device, Constant Temperature Coil, Material Tank Thermometer, Liquidometer
2	TDI	2 Ton,A3 Steel	NB2-C32F	Feeding Pump, Mixing device, Constant Temperature Coil, Material Tank Thermometer, Liquidometer
3	MC	500L 2mm Stainless Steel	NB2-D10F	Feeding Pump, Liquidometer
4	T9	50L 1mm Stainless Steel	HGP-2A-F2R
5	Silicone Oil	50L 1mm Stainless Steel	HGP-2A-F2R
6	A33	50L 1mm Stainless Steel	HGP-2A-F2R
7	Water	50L 1mm Stainless Steel	HGP-2A-F4R

Terms:

Terms of Payment: 30% advance payment by T/T upon signing the contract

70% covered by T/T before delivery

Installation and Start-up:

2 technicians will be assigned to coordinate installation, commissioning and training,

cost for flight and suitable accommodation plus USD60/day will be charged additionally.

Warranty: 12 months limited warranty. Starting from date of delivery excluding wear parts.

Shipping cost for parts to be replaced during warranty period have to be borne by the customer.

3.2 Mould

Quantity: 2sets

Size: W2100*L2450*H1200mm

35KW Sponge Mattress Foam Production Line High Speed 220L / Mould
